RM96.00 - RM336.00
Soild Bar Machined/Socket Weld Thermowell
Price RM96.00 - RM336.00
Product SKU PROWELL/SS316
Brand TEL-TRU
Availability 430
Size & Connection
89 left
64 left
36 left
147 left
41 left
53 left
Quantity
Description
Type 2.5"-1/2"NPT 4"-1/2"NPT 6"-1/2"NPT 4"-SOCKETWELD 6"-3/4"NPT 9"-3/4"NPT
Thermowell Style Tapered Tapered Tapered Straight Tapered Tapered
Material SS316 / SS316L SS316 / SS316L SS316 / SS316L SS316 / SS316L SS316 / SS316L SS316 / SS316L
Stem Length 2-1/2" 4" 6" 4" 6" 9"
Insertion "U" Length 1" (25 mm) 2-1/2" (63 mm) 4-1/2" (115 mm) 2-1/2" (63 mm) 4-1/2" (114 mm) 7.2" (183.60 mm)
Bore diameter 6.6 mm (0.26") 6.6 mm (0.26") 6.6 mm (0.26") 6.6 mm 6.6 mm (0.26") 6.6 mm (0.26")
Root Diameter 0.625" 0.625" 0.625" 12.7 mm 22 mm 22 mm
Tip Diameter 0.500" 0.500" 0.500" 12.7 mm 19 mm 16 mm
Pressure Rating       3,000 PSI
Connection Instruments - 1/2" NPT Female
 Process - 1/2" NPT Male Thread
Instruments - 1/2" NPT Female
                       Process - Socket Weld end
Instruments - 1/2" NPT Female
 Process - 3/4" NPT Male Thread





For other range, please contact us or drop us your enquiry by email
