Applications
- Intended for adverse service conditions where pulsating
or vibration exists (with liquid filling) - Hydraulics & compressors
- Suitable for gaseous or liquid media that will not obstruct
the pressure system
Special Features
- Vibration and shock resistant (with liquid filling)
- Stainless steel case
- Pressure ranges up to 15,000 psi
Sizes
- 2”, 2½” & 4” (50, 63 & 100 mm)
Ranges
- Vacuum / Compound to 200 psi Weather protection
- Pressure from 15 psi to 15,000 psi Weather tight (NEMA 4X / IP 65)
- Pressure from 15 psi to 10,000 psi – 2” size or other equivalent units of pressure or vacuum Pressure connection
Pressure connection
Material: Copper alloy
Lower mount (LM) or center back mount (CBM) – 2” & 2½”
Lower mount (LM) or lower back mount (LBM) -4″ ⅛”
NPT, ¼” NPT or ½” NPT limited to wrench flat areaABS (2” & 2½”) and white aluminum (4”)
